Incremental backups to untrusted hosts

There’s no point in encryption, passphrases, frequent updates, system hardening and retinal scans if all the data can be snapped up from the backup server. I’ve been looking for a proper backup system that can safely handle incremental backups to insecure locations, either my personal server or someone else’s.

This excludes a few of the common solutions:

  • Unencrypted backups with rsync. Prevents eavesdropping when done over ssh, but nothing else.
  • Rsync to encrypted partitions/images on the server. Protects against eavesdropping and theft, but not admins and root kits. Plus it requires root access on the server.
  • Uploading an encrypted tarball of all my stuff. Protects against everything, but since it’s not incremental, it’ll take forever.

My current best solution: An encrypted disk image on the server, mounted locally via sshfs and loop.

This protects data against anything that could happen on the server, while still allowing incremental backups. But is it efficient? No.

Here is a table of actual traffic when rsync uploads 120MB out of 40GB of files, to a 400gb partition.

Setup Downloaded (MB) Uploaded (MB)
ext2 580 580
ext3 540 1000
fsck 9000 300

Backups take about 15-20 minutes on my 10mbps connection, which is acceptable, even though it’s only a minute’s worth of actual data. To a box on my wired lan, it takes about 3 minutes.

Somewhat surprisingly, these numbers didn’t vary more than ±10MB with mount options like noatime,nodiratime,data=writeback,commit=3600. Even with the terrible fsck overhead, which is sure to grow worse over time as the fs fills up, ext2 seems to be the way to go, especially if your connection is asymmetric.

As for rsync/ssh compression, encryption kills it (unless you use ECB, which you don’t). File system compression would alleviate this, but ext2/ext3 unfortunately don’t have this implemented in vanilla Linux. And while restoring backups were 1:1 in transfer cost, which you’ve seen is comparatively excellent, compression would have cut several hours off of the restoration time.

It would be very interesting to try this on other FS, but there aren’t a lot of realistic choices. Reiser4 supports both encryption and compression. From the little I’ve gathered though, it encrypts on a file-by-file basis so all the file names are still there, which could leak information. And honestly, I’ve never trusted reiserfs with anything, neither before nor after you-know-what.

ZFS supposedly compresses for read/write speed to disk rather than for our obscure network scenario, and if I had to guess from the array of awesome features, the overhead is probably higher than ext2/3.

However, neither of these two FS have ubiquitous Linux support, which is a huge drawback when it comes to restoring.

So a bit more about how specifically you go about this:

To set it up:

#Create dirs and a 400gb image. It's non-sparse since we really
#don't want to run out of host disk space while writing.
mkdir -p ~/backup/sshfs ~/backup/crypto
ssh vidar@host mkdir -p /home/vidar/backup
ssh vidar@host dd of=/home/vidar/backup/diskimage \
        if=/dev/zero bs=1M count=400000

#We now have a blank disk image. Encrypt and format it.
sshfs -C vidar@host:/home/vidar/backup ~/backup/sshfs
losetup /dev/loop7 ~/backup/sshfs/diskimage
cryptsetup luksFormat /dev/loop7
cryptsetup luksOpen /dev/loop7 backup
mke2fs /dev/mapper/backup

#We now have a formatted disk image. Sew it up.
cryptsetup luksClose backup
losetup -d /dev/loop7
umount ~/backup

To back up:

sshfs -C vidar@host:/home/vidar/backup ~/backup/sshfs
losetup /dev/loop7 ~/backup/sshfs/diskimage
cryptsetup luksOpen /dev/loop7 backup
mount /dev/mapper/backup ~/backup/crypto

NOW=$(date +%Y%m%d-%H%M)
for THEN in ~/backup/crypto/2*; do true; done #beware y3k!
echo "Starting Incremental backup from $THEN to $NOW..."
rsync -xav --whole-file --link-dest="$THEN" ~ ~/backup/crypto/"$NOW"

umount ~/backup/crypto
cryptsetup luksClose backup
losetup -d /dev/loop7
umount ~/backup/sshfs

If you know of a way to do secure backups with less overhead, feel free to post a comment!

dd is not a backup tool!

Pretty much all Linux newbies will at some point be dazzled by the amazing powers of dd, and consider using it for backups. DON’T! Allow me to elaborate:

  1. dd must be run on an unmounted device. The point of using dd is usually to get a snapshot, but it’s not a snapshot if the system keeps running and modifying the FS while it’s being copied! The “snapshot” will be a random collection of all the states that the data and metadata were in during the 30+ minutes it took to copy.
  2. It’s hard to restore on a file by file basis. You hardly ever want to restore everything, usually you just want one file or directory that was accidentally deleted, or all files except the ones you’ve been working on since the backup was taken.
  3. It’s hard to restore to new hardware. If you suffer a massive disk crash, you will indeed want to restore everything. If you’re restoring to the same size disk, and you don’t decide that you want less swap or a bigger root partition while you’re at it, you can now easily restore and thank the gods that most FS don’t rely on disk geometry anymore. If you try to restore to a smaller disk on a secondary/old computer, you’re just screwed. If you upgrade to a larger disk (by far the most likely scenario), you’ll be playing the partition shuffle for a while to get use of the new space.
  4. It’s highly system dependent, and requires root to extract files. You can’t use your mum’s Wintendo or even your school’s Linux boxes to get out that geography report. And if you’re sick of Linux after it botched your system, you can’t switch to FreeBSD or OSX.
  5. You can’t do incremental backups. You can’t properly back up just the information that has changed. This all but kills network backups, and dramatically reduces the number of snapshots you can keep.

So when is dd a decent choice for backups?

Take a snapshot of a new laptop that doesn’t come with restoration disks, so that you can restore it if you sell the laptop to a non-geek or if the laptop needs servicing (it’ll make life easier for clueless techies, and companies have been known to use Linux as an excuse for not covering hardware repairs).

Create a disk image right before you try something major that you want to be able to reverse, such as upgrading to the latest Ubuntu beta to see if the new video driver works better with your card. Or right before installing Puppy Linux to write a little review about it. Restoring the image will be easier than downgrading/reinstalling, and you won’t have done any work in the mean time.

Image a computer and teach the kids how to install an operating system in a realistic scenario.

Visualization fun with GStreamer

I have a Mini-ITX box connected to my TV. It worked very well on my old CRT TV, but now I have a Full HD TV. It went from 720×576 to 1920×1080: five times the pixel count (exactly!), or over 100MB/s (bytes, not bits of course) of raw video. It’s not all that much, but it’s way more than what the Mini-ITX can handle. With the magic of graphics hardware, however, it can show lower resolutions scaled up to 1920×1080 without breaking a sweat.

I had a lot of issues trying to get some music visualization running on it. There’s no way the poor thing can generate 1920×1080 pixels worth of visualization, let alone push it out to the TV. libvisual, the closest thing to a visualization standard there is, didn’t appear to have simple command line apps that you could point to a music file and hardware scale the visualizations to fullscreen.

There was projectM though, which has a clever system of capturing audio from the Pulse audio system and visualizing it with OpenGL scaling. That way you can use any music playing app you want, at any resolution you care to render and display. Unfortunately, the Openchrome drivers for the VIA hardware and the Qt OpenGL component really hated each other.

But hey, we have GStreamer!

gst-launch-0.10 pulsesrc device=alsa_output.hw_0.monitor ! queue ! audioconvert ! libvisual_infinite ! video/x-raw-rgb,width=640,height=360,framerate=25/1 ! ffmpegcolorspace ! queue ! xvimagesink

Grab audio from the pulse monitor device, run it through libvisual to get a visualization at the specified resolution, and show it through xvideo. All my requirements summed up in about two lines of gstreamer goodness!

Webcam fun with GStreamer

I have yet to find a proper linux tool for recording video from a webcam while showing it on screen at the same time. The typical hack is to use mencoder to encode, and mplayer to play the encoded file, but the latency is typically a full second or more:

{ tail --follow=name -n +0 --retry "lulz.avi" | mplayer -cache 320 -vo x11 -; killall -INT mencoder; } & mencoder tv:// -tv width=640:height=480:fps=15 -ovc lavc -o lulz.avi

GStreamer does to video/audio what Bash does to text and NetPBM does to images, and it’s just as brilliant (possibly more). So let’s instead use it instead:

gst-launch-0.10 v4l2src ! tee name=videoout ! queue ! videorate ! video/x-raw-yuv,fps=15 ! queue ! theoraenc quality=60 ! queue ! muxout. pulsesrc ! audio/x-raw-int,rate=22000,channels=1,width=16 ! queue ! audioconvert ! vorbisenc ! queue ! muxout. oggmux name=muxout ! filesink location=lulz.ogg videoout. ! queue ! ffmpegcolorspace ! ximagesink

Voila. While long and seemingly convoluted, it’s not really worse than the mplayer line, and it works a lot better.

While a gst pipeline looks scary to begin with, it’s really self explanatory when you start reading it. Still, I’ll do a little dance about it:

#Get a v4l2 video source, split it and put one end though a
#theora codec and send the other to videoout (defined later)
v4l2src ! tee name=videoout ! queue ! videorate ! video/x-raw-yuv,fps=15 \
        ! queue  ! theoraenc quality=60 ! queue ! muxout.

#Get audio from a pulseaudio stream, run it through the vorbis encoder
pulsesrc ! audio/x-raw-int,rate=22000,channels=1,width=16 \
         ! queue ! audioconvert ! vorbisenc ! queue !muxout.

#Mux the audio and video together, and put it in "media.ogg"
oggmux name=muxout ! filesink location=media.ogg

#Put the other end of the video split out on the screen
videoout. ! queue ! ffmpegcolorspace ! ximagesink

Easy to see why this is one of my new favourite toys.


I suggest a simple number-to-string scheme for easily recognising and comparing numbers.

There seems to be a number of cases where you want to check that two numbers are the same. This could be comparing a number on a printed record to a number on screen, comparing document IDs over the phone, seeing if two people share a phone number, or a bunch of other scenarios. This is highly error prone. Given that you can raed wrods wrhee the lertets are mxied up wouthit porbelms, it’s no wonder that 85142 and 85412 are easily confused.

Humans are a lot better at concepts, and therefore words. Given the lines “snowman, blue kiwi” and “snowman, red camel”, anyone will easily see that they’re not the same. Even though “snowman, red camel” has three times as many characters as “85412”, I think most people would find the former easier for both long term and short term memorization.

These happen to be actual examples from a simple number-to-string conversion scheme I devised. It’s based on a set of ten adjectives and a hundred mostly cute and happy nouns. I call the resulting strings “cutecodes”. You can test them below, by typing in some digits and hoping that my javascript skills haven’t rotted.

Cutecode test:
Javascript off?

The digits are grouped in threes, the first digit picks an adjective and the last two pick a noun. Here are some thoughts that went into the system:

  • There should be a sizable amount of words. Here, an adjective and a noun will uniquely identify three digits. With some more work, you might have a hundred adjectives and a thousand nouns, for five digits.
  • The words should be pleasant and inoffensive, no matter which order they’re put in. People might object to having “burning deamon” as their order number. “Cutecodes” came from the resulting high concentration of cute nouns. I tried not making it sappy though, since it should be usable in a serious corporate setting.
  • Words should not be excessively culture specific. It’s hard making it global, but I avoided words like “gopher” which are primarly American. People will have a harder time remembering words if the concept are difficult to relate to. Since this is a proof of concept there are still some, like “lemur”.
  • With four digits you get two nouns rather than two adjectives and a noun. This is because a “small, green pencil” and “green, small pencil” is the same concept but would map to different numbers (with this rule, you get “ginger, pencil” instead)

It could be convenient to be able to convert cutecodes to numbers by hand. One way would be to use “A” and “B” as “0”, “C” and “D” as 1, etc, and picking the words so that “BArn” is 00, “CAlf” is “10” and so forth. So far, the nouns are just listed in alphabetical order, so you know that “earthworm, red carrot” is a lot less than “wizard, small mushroom”.

Instead of even trying, I chose single syllable adjectives and double syllable nouns, all with mostly the same rythm: “black camel, green lemur, sweet raincoat, young almond, white puzzle, small lemming, dry bubble”. This sounds nice and takes the same number of syllables to say as the number.

Finally, the words should be chosen so that they can be translated unambiguously between a few major languages. I didn’t bother with this either.

I imagine that this could be shown wherever strings of more than 3-4 digits are displayed, to increase recognition by humans.
